Model 22/23
Mid range single head automatic weighing machines specifically designed for general purpose applications, typically handling technical components, plastic mouldings, medical devices, etc.
The Comcount Model 22 and 23 series linear weighers are specifically designed to automatically weigh or weigh/count a wide range of industrial, technical, or medical components into pre-set batch quantities.
The system consists of a three stage vibratory feed system, an independent fine feed weighpan assembly with a precision weighing mechanism, and a Siemens control system with touch screen display.
The machines are identical in operation with the two separate frame sizes, each available with a range of alternative weight ranges to cover the widest possible range of applications and products.
Features:
- High precision weighing mechanism with alternative weigh range
- Weigh/count mode for parts with regular piece weight
- Independently driven fine feed with adjustable tooling
- Three stage vibratory feed system plus infeed
- Alternative feed widths to suit a wide range of applications
- Pre-weigh system to regulate product in the feed system
- Siemens control system with touch screen display
- Range of alternative infeed hoppers and elevators
- Optional reject system to limit product give-away
- Optional stainless contact parts for medical applications
